When an alarm sounds, red and yellow flashes are displayed to
indicate different alarm priorities. Red flashing = high, yellow flashing
= medium, steady yellow = low.
To bring up the main menu; display waveform changes; observe the
monitoring parameters; for executing repeat operations to close the
main menu.
For selecting adults or children.
Button for lead switching.
Corresponds to the hotkey on the screen. The function of the same
soft key is not the same under different operating modes.
Manually enable/disable NIBP measurement.
For sounding alarms and giving voice prompts.
System Alarm
Silence Button
Used for voice recording.
Rotate clockwise or counterclockwise to move the cursor Press:
pressing the knob to confirm an operation.
Press the button to provide defibrillation.
Press the button to charge the defibrillator.
Turn synchronization on/off.
For selecting a different mode.
Indicates the current battery status.
Indicates the current AC status.
• Main unit - rear view
