86
Basic ECG Monitoring Specifications
Sensitivity
2.5 mm/mV (×0.25), 5 mm/mV (×0.5), 10 mm/mV (×1), 20 mm/mV (×2), 40
mm/mV (×4) with errors less than ±5 %
Add ±300mV DC polarization voltage, the sensitivity variation range will be
±5 %
Scan Speed
50mm/s, 25mm/s, 12.5mm/s, 6.25mm/s, with errors less than ±10 %
Frequency
Characteristics
(ECG lead)
Treatment mode
1Hz-20Hz ( )
Monitoring mode
0.5Hz-40Hz ( )
Diagnostic mode
0.05Hz-150Hz ( )
Frequency
Characteristics
(Defibrillation
Electrode)
Treatment mode
1Hz-20Hz ( )
Common
Mode
Rejection
Capacity (ECG
lead)
Treatment mode
>105 dB
Monitoring mode
>105 dB
Diagnostic mode
(Available only in
monitoring mode)
>90 dB
Common
Mode
Rejection
Capacity
(Defibrillation
Electrode)
Treatment mode
>105 dB
Power
Frequency
Notch Filter
Treatment mode
The 50/60 Hz notch filter can be automatically enabled
Monitoring mode
Diagnostic mode
The 50/60 Hz notch filter can be manually set
Power frequency
interference
suppression
capability
≥20 dB
System Noise
≤25 μV (Peak-to-peak)
DC Bias
Voltage
±500 mV
Calibration
Voltage
1mV, error range ±5 %
