9-12

P129394-176 Operator Manual Troubleshooting

Alarm Description Screen with Operator Instructions

9.3.2 Too Long To

Open Door

Occurs if door switch

does not open within the

allotted time.

Screen with Service Instructions

STATUS . . ALARM! 245

TOO LONG TO OPEN DOOR

CHAMBER: 00.0 F 0.0 psig

STERILIZER WILL:

• REMAIN IN ALARM CONDITION UNTIL

DOOR IS OPENED

OPERAT0R INSTRUCTIONS:

1. SILENCE ALARM

2. CALL SERVICE

SERVICE

HELP

STATUS

SILENCE

ALARM

PAPER

FEED

STATUS . . SERVICE INFORMATION: 246

TOO LONG TO OPEN DOOR

-> DOOR SWITCH DID NOT OPEN IN ALLOTTED TIME

CAUSES AND CORRECTIONS:

1. DOOR SWITCH MALFUNCTION

-> CHECK LS1 (LS2) CONNECTIONS

-> READJUST LS1 (LS2)

2. POWER DOOR MECHANISM FAILURE

-> REPAIR MECHANISM

-> REPLACE MOTOR

PAPER

FEED

EXIT

CLEAR

ALARM
