9.4 Sensor Alarms The following alarm screens will appear (under alarm conditions) if
the sterilizer is energized. The sensors are continually monitored
whenever the sterilizer is in or out of cycle.
Alarm Description Screen with Operator Instructions
9.4.1 Water In
Chamber
Occurs if excess water
is sensed in the
chamber.
Screen with Service Instructions
STATUS . . ALARM! 209
WATER IN CHAMBER
CHAMBER: 00.0 F 0.0 psig
WARNING - BURN HAZARD!
CHAMBER MAY BE FILLED WITH STEAM CONDENSATE
OPERAT0R INSTRUCTIONS:
1. DO NOT OPEN DOOR
2. SILENCE ALARM
3. CALL SERVICE IMMEDIATELY
SERVICE
HELP
STATUS
PRINT
SILENCE
ALARM
PAPER
FEED
STATUS . . SERVICE INFORMATION: 210
WATER IN CHAMBER
-> EXCESS WATER SENSED IN CHAMBER,
WARNING! BURN HAZARD
CAUSES AND CORRECTIONS:
1. JACKET STRAINER PLUGGED
-> CLEAN
2. JACKET TRAP FAILED CLOSED
-> REPAIR
3. CHAMBER TRAP FAILED CLOSED
-> REPAIR
4. WATER ENTERED CHAMBER THROUGH STEAM PIPING
-> CHECK BOILER OR STEAM GENERATOR
-> REPAIR PIPING
5. WATER FLOAT SENSOR MALFUNCTION
-> REPAIR
PAPER
FEED
EXIT
