P129394-176 Operator Manual Component Identification
5.3 Control
Displays
Control displays can be divided into two categories, those occurring
when the sterilizer is “out-of-cycle” and those occurring when the
sterilizer is “in-cycle.”
Typical out-of-cycle and in-cycle displays are shown in Figure 5-3:
• Out-of-cycle displays are used to start cycles, or set up and
adjust sterilizer operation. With the exception of the cycle
starting displays, most out-of-cycle displays will only be used
occasionally. Detailed instructions for adjusting the sterilizer
operating parameters are in Section 7, Cycle and Control Value
Programming.
• Generally, when the sterilizer is in-cycle, displays appear
automatically and, unless an abnormal condition occurs, require
no special attention or instructions. In-cycle displays tell the
operator at what temperature and pressure the sterilizer
chamber is operating, show the current cycle phase, and
indicate when the processing cycle is complete. For more details
about operating cycles, refer to Section 6, Sterilizer Operation.
Figure 5-3. Typical Out-Of-Cycle and In-Cycle Displays
STATUS . . DOOR CLOSED 1
TEMP . . . 128 F
PRESS . . 0 PSIG
PRESS "MORE CYCLES" FOR GRAVITY & TEST.
1.270°F 2.270°F 3.275°F 4.270°F
PREVAC PREVAC PREVAC PREVAC
S=04 D=01 S=04 D=30 S=03 D=30 S=04 D=20
IMMEDIATE FULL LOAD FULL LOAD FULL LOAD
USE TRAY TRAY FABRIC
10:20:34 AM 10/08/10
STANDBY
MENU
PAPER
FEED
MORE
CYCLES
STATUS . .PURGE 1:00 4
TEMP . . .124 F
PRESS . . .0 psig
3.TRAY, PREVAC, 270F, 4, 30
PROJECTED CYCLE COMPLETION TIME:
15:20
MINUTES SECONDS
PAPER STATUS
FEED PRINT
ABORT
Out-of-Cycle In-Cycle
