7-2
P129394-176 Operator Manual Cycle and Control Value Programming
7.2 Change Cycle
Values
Refer to Figures 7-1 through 7-3.
7.2.1 Overview 1. Press the ON touch screen pad, if the sterilizer is in STANDBY.
The control advances to Status screen #1.
2. At screen #1, press the MENU touch screen pad, and the control
advances to screen #2; access the cycle values by pressing
CHANGE CYCLE VALUES.
3. Pressing CHANGE CYCLE VALUES advances the control to
screen #10, prompting the operator to select a cycle to change.
4. Press one of the displayed cycles, or MORE CYCLES to find a
cycle not currently on the display. Once the cycle has been
found and selected, the control advances to screen #11,
showing basic cycle information.
5. Select the value to change: NAME (name of the cycle), TEMP
(sterilize exposure temperature), STER (sterilize exposure time),
or DRY (drying phase time). Screen #11 can also be used to
enter up to two CUSTOM cycles names.
6. Press the touch screen touchpad; the display advances to a
screen for making these changes.
7. Once all selections have been made, press the EXIT touch
screen pad.
7.2.2 Adjusting Cycle
Sterilize Time and Dry Time
The following selections can be adjusted:
• NAME: For changing the cycle type.
• Prevacuum Configuration – PREVAC, GRAVITY or
LIQUID.
• SFPP Configuration – PREVAC, GRAVITY, SFPP or
LIQUID.
• CUSTOM1 and CUSTOM2 buttons on screen #11 can be
used to enter user-defined cycle names.
NOTE: When selecting a name, all other cycle values default to
the factory set values for that cycle.
LIQUID SFPPGRAVITYPREVAC
SELECT NEW CYCLE NAME
OR SELECT ANOTHER ITEM TO CHANGE
12
TEMP STER DRYNAME
NONE EXIT
