5-14
P129394-176 Operator Manual Component Identification
5.9 Power-Door
Operation
The sterilizer door is operated at the foot pedal (refer to Figure 5-10).
• Pressing the foot pedal while the door is in the closed (up)
position causes the door to open (lower).
• Pressing the foot pedal while the door is in the open (lowered)
position, causes the door to close (by raising).
On double door units, there is no control of the power door at the
opposite end of the unit. Each door of a double door sterilizer is
operated from the end at which the door is located.
Important: Keep the door closed when the unit is not in use.
WARNING – PERSONAL
INJURY HAZARD: When
closing the chamber door,
keep hands and arms out of
the door opening and ensure
opening is clear of any
obstructions.
Figure 5-10. Power Door Floor Pedal
