7-3
Cycle and Control Value Programming Operator Manual P129394-176
Cycle values (sterilize temperature and time, and dry time) are
adjustable within the limits shown in Table 7-1.
• TEMP: For changing sterilize exposure temperature within the
ranges shown.
• STER: For changing the sterilization exposure time. Use
number touchpads to enter a new value. Left and right arrow
touchpads can be used to cursor through an existing value.
• DRY: For changing the dry time.
NOTE: To return cycle values to original state, press RESTORE ALL
DEFAULT VALUES. This touchpad can also be used to cancel
previous changes to a cycle.
TEMP STER DRYNAME
SELECT NEW DRY TIME
OR SELECT ANOTHER ITEM TO CHANGE
RANGE = 0-99 MINUTES
13
1 2 3 RESTORE ALL
DEFAULT VAL-
UES
4 5 6
7 8 9
EXIT
<- 0 ->
Table 7-1. Adjustment Ranges for Cycle Values
Cycle Type Sterilize Time
Sterilize Temperature
*
* Sterilize time limits:
» Prevac or SFPP cycles set to a temperature of 270-274°F (132-134°C) are limited to a four-minute
minimum sterilize time.
» Prevac or SFPP cycles set to a temperature of 275°F (135°C) are limited to a three-minute minimum
sterilize time.
Dry Time
270°F (132°C) Prevac 4 - 99 minutes 270 - 274°F (132 - 134°C)
1 - 99 minutes
275°F (135°C) Prevac 3 - 99 minutes 275°F (135°C)
270°F (132°C) SFPP 4 - 99 minutes 270 - 274°F (132 - 134°C)
0 - 99 minutes
275°F (135°C) SFPP 3 - 99 minutes 275°F (135°C)
250°F (121°C) Gravity 30 - 99 minutes 250 - 269°F (121 - 131°C)
270°F (132°C) Gravity 3 - 99 minutes 270°F (132°C)
250°F (121°C) Liquid 45 - 99 minutes 250°F (121°C) N/A
Test Cycles
Dart (Bowie-Dick Test)
Dart Warm-Up
Leak Test
Values Cannot Be Adjusted
