3-3
Installation Verification Operator Manual P129394-176
3.2 Technical
Specifications
3.2.1 Overall Size • 16" Sterilizer: 26" wide x 74-1/2" high x 35-3/4" deep
(660 mm wide x 1892 mm high x 908 mm deep)
• 20" Sterilizer: 30" wide x 74-1/2" high x 45-1/8" deep
(762 mm wide x 1892 mm high x 1146 mm)
3.2.2 Weight
(Fully Loaded)
• 16" Sterilizer:
Single Door, Steam 750 lb (340 kg)
Double Door, Steam 989 lb (449 kg)
Single Door, Electric 890 lb (404 kg)
• 20" Sterilizer:
Single Door, Steam 1231 lb (558 kg)
Double Door, Steam 1606 lb (728 kg)
Single Door, Electric 1371 lb (622 kg)
Double Door, Electric 1726 lb (782 kg)
3.2.3 Utility Requirements • Electric:
Direct Steam: 120 Volt, 50/60 Hz, 1-phase, 9.5 Amps
Steam Generator: 208 Volt, 50/60 Hz, 3-phase,
83.2 Amps; 240 Volt, 50/60 Hz,
3-phase, 72.2 Amps; or
480 Volt, 50/60 Hz, 3-phase, 37 Amps
(if equipped)
• Water:
Pressure:
Sterilizer 30 to 50 psig (2.1 to 3.5 bar)
Steam Generator 20 to 50 psig (1.4 to 3.5 bar)
(if equipped)
Temperature:
Sterilizer 70°F (21°C) maximum
Steam Generator 140°F (60°C) optimum,
(if equipped) 150°F (66°C) maximum
Consumption:
Sterilizer 6.0 gpm (23 lpm)
Steam Generator 6.0 gpm (23 Ipm)
(if equipped)
• Steam:
Pressure: 50 to 80 psig (3.5 to 5.2 bar)
• Consumption:
16" Direct Steam 83 lb/hr (38 kg/h)
20" Direct Steam 116 lb/hr (53 kg/hr)
3.2.4 Environmental
Conditions
Temperature: 41 - 104°F (5 - 40°C)
Humidity: 85% noncondensing, maximum
Pollution Degree: 2
Installation Category (Overvoltage Category): II
A-Weighted Sound Power Level: 68 dBA (mean) -78 dBA (maximum)
