3-2
P129394-176 Operator Manual Installation Verification
3.1.3 Electrical Service ❑ Electric single-phase service to the unit must be as specified on
the Equipment Drawing and on the Sterilizer’s Data Plate.
❑ Electric single-phase service requires a clearly marked
disconnect with lockout/tagout capability located near the
sterilizer and installed according to local codes.
❑ Electric single-phase service should be on a separate circuit,
and not tied into circuits containing large reactive loads (e.g.,
motors).
❑ The protective earth ground must be connected to terminal
block TB-1 in the sterilizer power box.
3.1.4 Sterilizer Final Check ❑ Chamber leveled properly.
❑ Door opens and closes smoothly.
❑ Door locked switches adjusted correctly.
❑ Chamber strainer in place.
❑ Rack and shelves and/or loading car operates correctly.
❑ Paper loaded in printer.
❑ Printer ribbon properly installed.
❑ Warranty labels properly applied.
3.1.5 Cycle Operation ❑ Unit powers up correctly.
❑ Run Leak Test cycle – leak rate is to be less than 1.0 mm Hg/
minute (1.3 mbar/min).
❑ Verify operation of a typical cycle (270°F [132° C] prevacuum).
WARNING – EXPLOSION
HAZARD: This sterilizer is not
designed to process
flammable compounds.
