5-8
P129394-176 Operator Manual Component Identification
5.6 Cycle Selection
Touch-screen Pads
Four cycle selection touchpads are shown on the screen in
Figure 5-6. These pads display the basic parameters of the cycle:
•Cycle name
Sterilization exposure temperature
Sterilization exposure time
•Dry time
Additional cycles may be selected by pressing MORE CYCLES.
Details on individual cycles are in Section 6, Sterilizer Operation.
The AMSCO C Series Small Steam Sterilizer control can be
programmed to retain values for up to 12 separate cycles. User-
defined cycle names can be entered for cycles 1 and 2 on the cycle
selection screen.
Prevacuum Sterilizers The first six cycles (1 through 6) are
the factory default cycles and are routinely displayed on screen
#1 (press MORE CYCLES to access cycles 5 and 6). Up to six
additional cycles can be programmed and displayed.
Steam Flush Pressure Pulse (SFPP) Sterilizers The first five
cycles (1 through 4) are the factory default cycles and are
routinely displayed on screen #1 (press MORE CYCLES to
access cycle 5). Up to seven additional cycles can be
programmed and displayed.
Important: Applicable cycles have been validated to satisfy the
requirements outlined in Table 4-1 and Table 4-2. If cycle
parameters (sterilize time, dry time, temperature) other than those
listed are required, it is the responsibility of the healthcare facility to
follow the device manufacturer’s written instructions.
Dart
®
(Bowie-Dick) and Leak Test cycle parameters are fixed; the
buttons for these cycles do not display values for exposure
temperature, exposure time or drying time.
Figure 5-6. Cycle Selection Touchpads
STATUS . . DOOR CLOSED 1
TEMP . . . 128.0 F
PRESS . . . 0 PSIG
PRESS "MORE CYCLES" FOR GRAVITY & TEST.
1.270°F 2.270°F 3.275°F 4.270°F
PREVAC PREVAC PREVAC PREVAC
S=04 D=01 S=04 D=30 S=03 D=30 S=04 D=20
IMMEDIATE FULL LOAD FULL LOAD FULL LOAD
USE TRAY TRAY FABRIC
10:20:34 AM 10/08/10
STANDBY
MENU
PAPER
FEED
MORE
CYCLES
Press one of these
buttons to start a
cycle
Press this button
to access MORE
CYCLES
