Preliminary Technical Data UG-1828
Rev. PrC | Page 135 of 338
ATTEN
dB
= 20 × log10
256 _ _
256
fe gain cw[7 : 0]
−
The fe_gain_cw[7:0] is a 8 bit control word defined in the receiver gain table. Based on the information from the signal detectors, the gain
control algorithm will find the index of this gain table so that the corresponding gain control word at this index could be used to calculate
the gain at the front end attenuator. See the Rx Gain Control section for more details.
Mixer
Following the RF attenuator is the passive down converting mixer. It is used to down convert the RF signal to IF or baseband. The passive
mixer uses non-overlapping ¼ duty cycle local oscillator generated by the 4 phase 50% duty cycle LO. The non-overlapping time is
controlled by the duty cycle distortion (DCD) circuit. The DCD is implemented by delaying the rising edge of the 50% duty cycle LO.
LPF
In the receiver data chain, the LPF sits between the mixer and the ADC as a receiver baseband filter, supporting a baseband bandwidth of
5-50MHz. It also converts the baseband signal current to voltage. The capacitor arrays are implemented to program the various cut-off
frequencies based on the system requirements. In addition, along with other AFE components, it provides a static gain of about 20dB
which is independent of the gain control functionality through the receiver data chain.
The LPF could be configured in transimpedance amplifier (TIA) mode with single pole or in bi-quad (BIQ) mode with 2 complex poles
in the transfer function. While the in-band performance of both modes is similar, the BIQ mode offers additional advantages comparing
with the TIA mode, such as improving anti-alias filtering which might be necessary while using LP ADC. However, the use of the BIQ
mode consumes about twice the power than the TIA mode.
The LPF is calibrated during device initialization to ensure a consistent frequency corner across all devices. The 3 dB bandwidth is set
within the device data structure and is profile dependent. The user could optionally tune the 1dB/3dB cutoff frequency of the LPF based
on their application. ADRV9001 also allows user to configure LPF at 3 different power consumption levels to help achieve system power
saving target.
ADC
As mentioned previously, the ADRV9001 provides a pair of HP ADCs and a pair of LP ADCs to achieve a flexible trade-off between
power consumption and linearity performance. The HP ADC is based on Continuous Time Delta Sigma (CTDS) architecture and is 5-
bits wide. The LP ADC is based on voltage-controlled oscillator (VCO) architecture and is 16-bits wide. Each type of ADC is capable of
accepting the same input voltage, but the output bus width is different due to the different modulator orders and presence of linearity
correction in the LP ADC.
HP and LP ADCs provide a similar level of noise and dynamic range (full scale to thermal noise) performance. Therefore, the noise figure
(NF) performance is similar at the input. (Even with slight NF difference at the device input, the difference at antenna input would be
smaller as a result of the LNA gain in the front end.) The major difference between HP and LP ADC is the linearity performance and
power consumption. The intermodulation distortion (IMD) performance of HP ADC is slightly better than LP ADC, at the expense of
higher power consumption. Please refer to the data sheet for detailed information.
Given the high dynamic range of both the HP and LP ADC, very little channelization or blocker filtering occur in the analog signal chain
since the HP ADC can simultaneously absorb weak signals and large blockers. Blocker suppression and channelization are then achieved
efficiently in the digital signal path.
Therefore, HP ADC provides the maximum interferer tolerance, performance and LP ADC provides the best power consumption
performance under slightly relaxed interferer condition. Based on the application, the user is allowed to select between HP and LP ADC
for linearity and power consumption performance trade-off. In addition, user is allowed to dynamically switch HP ADC and LP ADC on
the fly through API commands adi_adrv9001_Rx_AdcSwitchEnable_Set( ) and adi_adrv9001_Rx_AdcSwitch_Configure( ). The first API
function is used to enable the ADC switching feature, and it should be called at STANDBY state before initial calibrations. When dynamic
ADC switch is enabled, both HP ADC and LP ADC initial calibrations will be performed. The second API configures the ADC switching
functionality for a specified receiver channel to operate in different modes. It should be called at CALIBRATED state after performing
initial calibrations.
When receiver Monitor Mode (not supported currently) is enabled, the device might switch between the HP ADC and LP ADC to reduce
power consumption. Additional algorithms are employed in ADRV9001 to compensate for the gain and delay differences while operating
with different type of ADCs so any internal switch is transparent to users.
