• Make sure that enSpiStreaming = 1 - a multi-byte data transfer is allowed.
• Force the CSB line low and keep it low until the last byte is transferred.
• Send the instruction word 0_000 0000 0010 1010 (the first 0 indicates a write operation) to select 0x02A as the starting address.
• Use the next 32 clock cycles to send the data to be written to the registers, MSB to LSB for each 8-bit word.
• Make sure the CSB line is driven high after the last bit has been sent to 0x027 to end the data transfer.
TIMING DIAGRAMS
The diagrams in Figure 21 and Figure 22 illustrate the SPI bus waveforms for a single-register write operation and a single-register read
operation, respectively. In the first figure, the value 0x55 is written to register 0x00A. In the second value, register 0x00A is read, and the
value returned by the device is 0x55. If the same operations were performed with a 3-wire bus, the SDO line in Figure 21 would be
eliminated, and the SDIO and SDO lines in Figure 22 would be combined on the SDIO line. Note that both operations use MSB-first
mode and all data is latched on the rising edge of the SCLK signal.
WRITE TO REGISTER 0x00A – VALUE = 0x55
24159-021
CSB
SCLK
SDIO
SDO
Figure 20. Nominal Timing Diagram, SPI Write Operation
READ REGISTER 0x00A – VALUE = 0x55
CSB
SDIO
SCLK
SDO
24159-022
Figure 21. Nominal Timing Diagram, SPI Read Operation
Table 13 lists the timing specifications for the SPI bus. The relationship between these parameters is shown in Figure 23. This diagram
shows a 3-wire SPI bus timing diagram with the device returning a value of 0xD4 from register 0x00A and timing parameters marked.
Note that this is a single read operation, so the bus-ready parameter after the data is driven from the device (t
HZS
) is not shown in the
diagram.
Table 13. SPI Bus Timing Constraint Values
Parameter Min Typical Max Description
t
CP
20 ns SCLK cycle time (clock period)
t
MP
10 ns SCLK pulse width
t
SC
3 ns CSB setup time to first SCLK rising edge
t
HC
0 ns Last SCLK falling edge to CSB hold
t
S
2 ns SDIO data input setup time to SCLK
t
H
0 ns SDIO data input hold time to SCLK
t
CO
3 ns 8 ns SCLK falling edge to output data delay (3-wire or 4-wire mode)
t
HZM
tH t
CO
(max) Bus turnaround time after baseband processor drives the last address bit
t
HZS
0 ns t
CO
(max) Bus turnaround time after device drives the last data bit
