UG-1828 Preliminary Technical Data

Rev. PrB | Page 242 of 277

Pin No. Type Mnemonic Unused instructions

P5 Input TX2_QDATA_IN+ Do not connect

P6 Input TX2_IDATA_IN+ Do not connect

P7 Input TX2_IDATA_IN- Do not connect

P8 Input TX1_IDATA_IN- Do not connect

P9 Input TX1_IDATA_IN+ Do not connect

P10 Input TX1_QDATA_IN+ Do not connect

P11 Input TX1_QDATA_IN- Do not connect

P12 Input/Output TX1_STROBE_IN- Do not connect

P13 Input TX1_STROBE_IN+ Do not connect
