Figure 264. Radio State Window
POWER MONITORING
The ADRV9001 evaluation software allows user to monitor power usage of the system. On top there is a button Power Monitoring,
which shows detailed voltage, current and power status of each power domain. Below is a screenshot of the power monitor window.
Note the VDDA_1P0 power domain is currently not supported by ADRV9002 and its readback should be ignored.
Figure 265. Power Monitoring Window
