Preliminary Technical Data UG-1828
Rev. PrB | Page 39 of 277
1. Call adi_adrv9001_Radio_ChannelEnableMode_Set( ) to set the PIN mode
2. Toggle the pins (for example, Rx1_ENABLE and Tx1_ENABLE pins for Channel 1) to transition the channel to the RF enabled
state.
SPI Mode
1. Call adi_adrv9001_Radio_ChannelEnableMode_Set( ) to set the SPI mode
2. Call adi_adrv9001_Radio_Channel_EnableRf( ) to transition the channel to the RF enabled state.
SHUTDOWN SEQUENCE
After completing all the operations, call API adi_adrv9001_Shutdown() through TES to safely shut down the ADRV9001 device. It
performs a hardware reset to reset the ADRV9001 device into a safe state for shutdown or re-initialization.
