127
Electronic Notepad (Continued)
Entering Bolt-Hole/Linear-Hole Patterns
The DRO allows you to store a bolt-hole or linear-hole pattern on one line in the
Electronic Notepad (only in Absolute Mode).
NOTE: To use a bolt-hole or linear/frame-hole pattern in the Electronic Notepad, you
must first program the hole pattern using the Advanced Functions, Bolt-Hole
Pattern function.
If you are not already in the enter program mode:
1. Press
ENT
to enter information into the
Electronic Notepad:
The DRO displays the following in the message window:
Enter
prog
To enter a hole pattern into the Electronic Notepad:
2. Press
ADV
The DRO displays one of the following in the message window:
Bolt hole
Lin
hole
3. Press
+
_
to toggle between bolt-hole
pattern and linear-hole
pattern.
