Anilam Wizard 900 - Page 186

180
Spark-Out/SparkArrest
TM
Setup, Relay 2
(900E Only) – F 39 (Continued)
To set up the SparkArrest
TM
limit (For example, -1.1):
NOTE: The SparkArrest
TM
limit is a negative value because it is located above the zero
position.
3. Press
+
_
to set the SparkArrest
TM
limit
to –1.1 and exit Relay 2
setup.
The DRO displays one of the following in the message window:
Cont open Cont close
4. Press
+
_
to toggle between the
settings and set the feature.
The DRO displays one of the following in the message window:
Dir signal Coin pulse
5. Press
+
_
to toggle between the
settings and set the feature.
If you select COIN PULSE (Coincidence Pulse):
6. Press
+
_
to scroll through the settings
and select the dwell time.
