ARC Audio PS8 - ARC Audio PS8: External Dimensions; ARC Audio PS8: Mounting Dimensions; PS8 Dimensions

GND
+12V
REMOTE - INPUT
REMOTE - OUTPUT
PROFILE 1 PROFILE 2
ILLUMINATION
SIGNAL GROUND
ANALOG
INPUT
RCA
SPEAKER
INPUT LEVEL
+9 - +15v
USB DISPLAY CH6 CH5 CH4 CH3 CH2 CH1
DC IN
ADVANCED DIGITAL SOUND PROCESSOR
DIGITAL
INPUT
CH 1/2
AUX IN
CH 5/6
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
OUTPUT
250mm
130mm
30mm
222mm
106mm
70mm
245mm
5.2- PS8 Dimensions
ARC Audio PS8: External Dimensions
ARC Audio PS8: Mounting Dimensions
