iPAM400 – Product Manual
U-0629-0171.doc – Issue: 04 complete, approved
Page 117 of 138
ASL Part Number Additional Information
201361 2-way plugable Wago cage clamp terminal (male)
Function: Auxiliary DC supply output cabling termination
Location: Rear panel
Manufacturer/Supplier: Wago
Manufacturer/Supplier Part No.: 231-632
Manufacturer/Supplier Description: Male connector; 2 pole; pin spacing 5.08 mm /
0.2 in; CAGE CLAMP®connection
201545 4-way plugable Wago cage clamp terminal (male)
Function: Loudspeaker line cabling termination
Location: Rear panel
Manufacturer/Supplier: Wago
Manufacturer/Supplier Part No.: 231-634
Manufacturer/Supplier Description: Male connector; 4 pole; pin spacing 5.08 mm /
0.2 in; CAGE CLAMP®connection
207784 8-way plugable Wago cage clamp terminal (female)
Function: Audio/Data cabling termination
Location: Rear panel
Manufacturer/Supplier: Wago
Manufacturer/Supplier Part No.: 734-208
Manufacturer/Supplier Description: Female plug; 8 pole; pin spacing 3.8 mm /
0.15 in; 100% protected against mismating; with codig fingers; CAGE
CLAMP®connection
A0477012 1.5 m battery connection cable
Function: Connection of DC supply to the mainframe
Location: Connected to BATTERY IN connector on the rear panel
Manufacturer/Supplier: Application Solutions (Safety and Security) Limited
Manufacturer/Supplier Part No.: A0477012
Manufacturer/Supplier Description: Battery connection cable, 1.5 m length, LSZH
cable
201555 Lithium battery
Function: Battery for RTC
Location: Controller board
Manufacturer/Supplier: Duracell
Manufacturer/Supplier Part No.: CR2032
Manufacturer/Supplier Description: Lithium battery
208078 Flash drive (blank)
Function: Data storage device
Location: Controller board
Manufacturer/Supplier: Miles Industrial Electronics Ltd
Manufacturer/Supplier Part No.: DJ0020G88RN0
Manufacturer/Supplier Description: Flash Memory Module Turbo I-Dom 40pin Ide
Vertical W/Housing
208081 Flash drive (iPAM400 image)
Function: Data storage device
Location: Controller board
Manufacturer/Supplier: Application Solutions (Safety and Security) Limited
Manufacturer/Supplier Part No.: 208081
Manufacturer/Supplier Description: Flash memory with iPAM400 image loaded
