Manual, Air Module, AH2
Document #9620-20-D-AH2-09
Pinnacle Park • 1031 Goodworth Drive • Apex, NC 27539 • Tel: 919.772.0115 • Fax: 919.772.8259 • www.ati-ia.com • Email: info@ati-ia.com
D-13
Table 7.4—AH4 ToolModuleSpecications
9121-AH4-T Pneumatic Tool module with (8) 3/8 G self-sealing ports
Materials of Construction
Various - Stainless Steel valve components, aluminum housing, Nitrile
seals
Weight: 2.31 lbs. (1.05 kg)
Self-sealing Valves:
Quantity
Air Pressure
Cv, Min
Customer Port Connection
8
Maximum pressure of 100 psi (6.9 bar)
1.6
G 3/8 (BSPP)
