All pneumatic and uid components (i.e. ttings, tubing) must be capable of withstanding the repetitive
motions of the application without failing. The routing of electrical, uid, and pneumatic lines must
minimize the possibility of stress/strain, kinking, rupture, etc. Failure of critical electrical, uid, or
pneumatic lines to function properly may result in injury to personnel and equipment.
All electrical power, pneumatic and uid circuits should be disconnected during servicing.
2.3 Safety Precautions
WARNING: Removealltemporaryprotectivematerials(caps,plugs,tape,etc.)on
lockingfaceofToolChangerandmodulespriortooperation.Failuretodosowillresult
indamagetoToolChangers,modules,andend-of-armtoolingandcouldcauseinjury
to personnel.
WARNING: DonotperformmaintenanceorrepaironToolChangerormodulesunless
theToolissafelysupportedordockedinthetoolstand,allenergizedcircuits(e.g.
electrical,air,water,etc.)areturnedoff,pressurizedconnectionspurgedandpower
dischargedfromcircuitsinaccordancewiththecustomer’ssafetypracticesand
policies.InjuryorequipmentdamagecanoccurwithToolnotdockedandenergized
circuitson.DocktheToolsafelyinthetoolstand,turnoffanddischargeallenergized
circuits,purgeallpressurizedconnections,verifyallenergizedcircuitsarede-energized
beforeperformingmaintenanceorrepaironToolChangerormodules.
WARNING: Duringoperation,theareabetweentheMasterandToolmustbekept
clear.FailuretokeepareaclearwillresultindamagetoToolChanger,modules,orend-
of-armtoolingandcouldcauseinjurytopersonnel.
WARNING: TheToolChangerisonlytobeusedforintendedapplicationsand
applicationsapprovedbythemanufacturer.UsingtheToolChangerinapplications
otherthanintendedwillresultindamagetoToolChanger,modules,orend-of-arm
toolingandcouldcauseinjurytopersonnel.
CAUTION:TheMasterplatelockingmechanismmustnotbeactuatedwithoutbeing
mountedtotherobotinterfaceplate.DamagetotheCoverplateandO-ringmayresult.
AlwaysattachtheMasterplatetotherobotinterfaceplatepriortoattemptingany
operations.

ATI Technologies QC-210 Specifications

General

Brand	ATI Technologies
Model	QC-210
Category	Industrial Equipment
Language	English
