Manual, Air Adapters
Document #9620-20-C-Jxx Air Adapters-02
Pinnacle Park • 1031 Goodworth Drive • Apex, NC 27539 • Tel: 919.772.0115 • Fax: 919.772.8259 • www.ati-ia.com • Email: info@ati-ia.com
C-13
8.2 Air Adapter for QC-310
3rd ANGLE PROJECTION
1
2
31.8
Ledge Mount
Ledge Mount
Lock Air Port
(Refer to Table 1 for
Model and port size)
Unlock Air Port
(Refer to Table 1 for
Model and port size)
158.8
67.4
9121-JA3-M Air Adapter (Shown)
1
Notes:
The air adapters are designed to mount to QC-310, QC-313, QC-510 and QC-1210 Tool
1.
Changers.
Other models are covered in the 9620-20-C-Jxx Air Adapters manual.
2.
The air adapter should be supplied dry, non-lubricated air at 60 to 100 psi (4.1-6.9 Bar) and
3.
filtered at 40 microns or better.
It is important that exhaust mufflers are not restricted. As part of a preventative maintenance
4.
program, periodically inspect and/or replace the exhaust mufflers.
Rev.
Description
Initiator
Date
02
ECO13408. Drawing Release.
JGH
1/7/2016
ITEM
NO.
QTY
PART NUMBER
DESCRIPTION
1 2
3500-1064020-15A
M5-0.8 x 20mm SHCS, Blue, Pre-Applied
2 2
3500-1066016-15A
M6-1 x 16mm SHCS, Blue, Pre-Applied
B
1:2
1 1
REVISION
NOTES: UNLESS OTHERWISE
SPECIFIED.
DO NOT SCALE DRAWING.
ALL DIMENSIONS ARE IN
MILLIMETERS.
DRAWN BY:
CHECKED BY:
J. Handy, 1/7/16
W Berrocal, 9/9/16
TITLE
SCALE
SIZE
DRAWING NUMBER
PROJECT #
SHEET OF
9630-20-Jxx Air Adapters for QC-310
02
PROPERTY OF ATI INDUSTRIAL AUTOMATION, INC. NOT TO BE REPRODUCED IN ANY
MANNER EXCEPT ON ORDER OR WITH PRIOR WRITTEN AUTHORIZATION OF ATI.
1031 Goodworth Drive, Apex, NC 27539, USA
Tel: +1.919.772.0115 Email: info@ati-ia.com
Fax: +1.919.772.8259 www.ati-ia.com
ISO 9001 Registered Company
Air Adapter, QC-310
