Manual, Air Adapters

Document #9620-20-C-Jxx Air Adapters-02

Pinnacle Park • 1031 Goodworth Drive • Apex, NC 27539 • Tel: 919.772.0115 • Fax: 919.772.8259 • www.ati-ia.com • Email: info@ati-ia.com

C-11

7. Specications

Table 5.3—AirAdapterSpecications

All Air Adapter Models Specication

Air Pressure 60 - 100 psi (4.1 – 6.9 Bar) clean, dry, non-lubricated air

Air Filtration 50 microns

9121-JA2-M Air Adapter NPT, QC-113, QC-210, QC-213, GL6L, GL7L

Pneumatic Connection 1/4” NPT

Weight 1.64 lbs (0.744 kg)

9121-JA3-M Air Adapter NPT, QC-310, QC-313, QC-510, QC-1210

Pneumatic Connection 1/4” NPT

Weight 1.92 lbs (0.87 kg)

9121-JB2-M Air Adapter G, QC-113, QC-210, QC-213, GL6L, GL7L

Pneumatic Connection G 1/4

Weight 1.66 lbs (0.75 kg)

9121-JB3-M Air Adapter G, QC-310, QC-313, QC-510, QC-1210

Pneumatic Connection G 1/4

Weight 1.94 lbs (0.88 kg)

9121-JB4-M Air Adapter with SST Mounting Screws G, QC-310, QC-313, QC-510, QC-1210

Pneumatic Connection G 1/4

Weight 1.94 lbs (0.88 kg)

9121-JB8-M Air Adapter with Revered Air Ports G, QC-113, QC-210, QC-213, GL6L, GL7L

Pneumatic Connection G 1/4

Weight 1.66 lbs (0.75 kg)

9121-JP2-M Air Adapter BSPT, QC-113, QC-210, QC-213, GL6L, GL7L

Pneumatic Connection 1.64 lbs (0.744 kg)

Weight xxx lbs (xxx kg)

9121-JP3-M Air Adapter BSPT, QC-310, QC-313, QC-510, QC-1210

Pneumatic Connection 1/4” BSPT

Weight 1.92 lbs (0.87 kg)

Table 5.4—ToolAdapterAssemblySpecications

9005-20-1192

Tool Adapter Assembly, QC-210, QC-213, QC-310, QC-313, QC-510, QC-1210, GL6L,

or GL7L

Weight

1.33 lbs (0.603 kg)
