ATI Technologies QC-210 - 7 Specifications

Manual, Air Module, AH2
Document #9620-20-D-AH2-09
Pinnacle Park • 1031 Goodworth Drive • Apex, NC 27539 • Tel: 919.772.0115 • Fax: 919.772.8259 • www.ati-ia.com • Email: info@ati-ia.com
D-12
7. Specications
Table 7.1—AH2MasterModuleSpecications
9121-AH2-M Pneumatic Master module with (8) G 3/8 self-sealing ports
Materials of Construction
Various - Stainless Steel valve components, aluminum housing, Nitrile
seals
Weight: 2.87 lbs. (1.30 kg)
Self-sealing Valves:
Quantity
Air Pressure
Cv, Min
Customer Port Connection
8
Maximum pressure of 100 psi (6.9 bar)
1.6
G 3/8 (BSPP)
Table 7.2—AH2ToolModuleSpecications
9121-AH2-T
Pneumatic Tool module with (8) G 3/8 Ports, 4 self-sealing/4
pass-through ports
Materials of Construction
Various - Stainless Steel valve components, aluminum housing, Nitrile
seals
Weight: 2.21 lbs. (1.0 kg)
Pass Through Ports:
Quantity
Air Pressure
Cv, Min
Customer Port Connection
4
Maximum pressure of 100 psi (6.9 bar)
1.6
G 3/8 (BSPP)
Self-sealing Valves:
Quantity
Air Pressure
Cv, Min
Customer Port Connection
4
Maximum pressure of 100 psi (6.9 bar)
1.6
G 3/8 (BSPP)
Table 7.3—AH3ToolModuleSpecications
9121-AH3-T Pneumatic Tool module with (8) 3/8 G pass-through ports
Materials of Construction
Various - Stainless Steel valve components, aluminum housing, Nitrile
seals
Weight: 2.11 lbs. (0.96 kg)
Pass Through Ports:
Quantity
Air Pressure
Cv, Min
Customer Port Connection
8
Maximum pressure of 100 psi (6.9 bar)
1.6
G 3/8 (BSPP)
