Manual, Air Adapters
Document #9620-20-C-Jxx Air Adapters-02
Pinnacle Park • 1031 Goodworth Drive • Apex, NC 27539 • Tel: 919.772.0115 • Fax: 919.772.8259 • www.ati-ia.com • Email: info@ati-ia.com
C-3
A tool adapter assembly (9005-20-1192) is required for the Tool side which provides the proper spacing and a ledge
mount for the control/signal Tool module.
Figure 1.3—Tool Adapters Assembly
Ledge Mount Feature for
Control/Signal Tool Module
Tool Adapter Assembly
(9005-20-1192)
