The Acyclic OUT area (input to PowerMACS) using 03: Holding Register:
Special address map
PM4000 uses Anybus-CC modules as fieldbus interfaces. The address map for this, seen from the
fieldbus, is different from the predecessor Anybus-S, which is used in PM Classic and PowerFocus.
It is possible to get a form of compatibility by marking the Special address map checkbox. The address
map will then resemble the one in Anybus-S for function 23, the combined Read/Write Multiple registers.
