AudioCodes Mediant 3000 User Manual

Version 7.0 1049 Mediant 3000
User's Manual 58. Configuration Parameters Reference
Parameter Description
where two DSP channels are used per transcoding session.
 Other DSP channels can be used for PSTN interfaces.
Automatic Gain Control (AGC) Parameters
Enable AGC
[EnableAGC]
Enables the AGC mechanism. The AGC mechanism adjusts the level
of the received signal to maintain a steady (configurable) volume level.
 [0] Disable (default)
 [1] Enable
Notes:
 The parameter can also be configured for a Tel Profile (in the Tel
Profile table).
 For a description of AGC, see Automatic Gain Control (AGC) on
page 225.
AGC Slope
[AGCGainSlope]
Determines the AGC convergence rate:
 [0] 0 = 0.25 dB/sec
 [1] 1 = 0.50 dB/sec
 [2] 2 = 0.75 dB/sec
 [3] 3 = 1.00 dB/sec (default)
 [4] 4 = 1.25 dB/sec
 [5] 5 = 1.50 dB/sec
 [6] 6 = 1.75 dB/sec
 [7] 7 = 2.00 dB/sec
 [8] 8 = 2.50 dB/sec
 [9] 9 = 3.00 dB/sec
 [10] 10 = 3.50 dB/sec
 [11] 11 = 4.00 dB/sec
 [12] 12 = 4.50 dB/sec
 [13] 13 = 5.00 dB/sec
 [14] 14 = 5.50 dB/sec
 [15] 15 = 6.00 dB/sec
 [16] 16 = 7.00 dB/sec
 [17] 17 = 8.00 dB/sec
 [18] 18 = 9.00 dB/sec
 [19] 19 = 10.00 dB/sec
 [20] 20 = 11.00 dB/sec
 [21] 21 = 12.00 dB/sec
 [22] 22 = 13.00 dB/sec
 [23] 23 = 14.00 dB/sec
 [24] 24 = 15.00 dB/sec
 [25] 25 = 20.00 dB/sec
 [26] 26 = 25.00 dB/sec
 [27] 27 = 30.00 dB/sec
 [28] 28 = 35.00 dB/sec
 [29] 29 = 40.00 dB/sec
 [30] 30 = 50.00 dB/sec
 [31] 31 = 70.00 dB/sec
AGC Redirection Determines the AGC direction.
