AudioCodes Mediant 3000 User Manual

Version 7.0 149 Mediant 3000
User's Manual 13. Network
Parameter Description
OAMP, and Control network types (configured with the
EnableNetworkPhysicalSeparation parameter) is disabled.
 VLANs are available only when booting the device from flash. When
booting using BootP/DHCP protocols, VLANs are disabled to allow
easier maintenance access. In this scenario, multiple network
interface capabilities (including IPv6) are unavailable.
Web/EMS: Native VLAN ID
[VLANNativeVLANID]
Defines the Native VLAN ID. This is the VLAN ID to which untagged
incoming traffic is assigned. Outgoing packets sent to this VLAN are
sent only with a priority tag (VLAN ID = 0).
When the Native VLAN ID is equal to one of the VLAN IDs listed in the
Multiple Interface table (and VLANs are enabled), untagged incoming
traffic is considered as incoming traffic for that interface. Outgoing traffic
sent from this interface is sent with the priority tag (tagged with VLAN ID
= 0).
When the Native VLAN ID is different to any value in the 'VLAN ID'
column in the table, untagged incoming traffic is discarded and all
outgoing traffic is tagged.
The default Native VLAN ID is 1.
Note: If this parameter is not configured (i.e., default value is 1) and one
of the interfaces has a VLAN ID set to 1, this interface is still considered
the ‘Native’ VLAN. If you do not wish to have a ‘Native’ VLAN ID and
want to use VLAN ID 1, set this parameter to a value other than any
VLAN ID in the table.
Network Physical
Separation
[EnableNetworkPhysicalSe
paration]
Enables the Physical Network Separation feature where network
interface types (Media, Control, and OAMP) are allocated to dedicated
ports. To define the port allocation, see the
PhysicalSeparationConfiguration parameter.
 [0] Disable (default).
 [1] Enable.
Notes:
 The parameter is applicable only to Mediant 3000 with TP-8410.
 For the parameter to take effect, a device reset is required.
 When the parameter is enabled, VLANs are not supported (i.e.,
VLANMode is set to 1).
 For a description of the Physical Network Separation feature, see
Physical Network Separation Mode on page 661.
Physical Separation
Configuration
[PhysicalSeparationConfig
uration]
Defines the port allocation for the Physical Network Separation feature.
 [0] 3 Interfaces: M + C+ OAMP = (Default) Each interface is
allocated a dedicated port:

Media on the GE port of the RTM

Control on port labeled 1 of the PEM

OAMP on port labeled 2 of the PEM
 [1] 3 Interfaces: M&C + OAMP = Media and Control are allocated to
the same port (GE port of RTM) and OAMP is allocated to a
dedicated port (Port 2 of PEM). In the Interface table, make sure
that you have configured an interface for OAMP only ('Application
Type' field set to OAMP) and configured all other interfaces for
Media and Control combined ('Application Type' field set to Media +
Control).
Notes:
