User's Manual 148 Document #: LTRT-89730
Mediant 3000
Parameter Description
th]
the number of bits which are set in the dotted-decimal format. For
example, 192.168.0.0/16 is synonymous with 192.168.0.0 and subnet
255.255.0.0. This CIDR lists the number of ‘1’ bits in the subnet mask
(i.e., replaces the standard dotted-decimal representation of the subnet
mask for IPv4 interfaces). For example, a subnet mask of 255.0.0.0 is
represented by a prefix length of 8 (i.e., 11111111 00000000 00000000
00000000) and a subnet mask of 255.255.255.252 is represented by a
prefix length of 30 (i.e., 11111111 11111111 11111111 11111100).
The prefix length is a Classless Inter-Domain Routing (CIDR) style
presentation of a dotted-decimal subnet notation. The CIDR-style
presentation is the latest method for interpretation of IP addresses.
Specifically, instead of using eight-bit address blocks, it uses the
variable-length subnet masking technique to allow allocation on
arbitrary-length prefixes.
The prefix length for IPv4 must be set to a value from 0 to 30. The
prefix length for IPv6 must be set to a value from 0 to 64.
Default Gateway
[InterfaceTable_Gateway]
Defines the IP address of the default gateway for the interface. When
traffic is sent from this interface to an unknown destination (i.e., not in
the same subnet and not defined for any static routing rule), it is
forwarded to this default gateway.
VLAN ID
[InterfaceTable_VlanID]
Defines a VLAN ID for the interface. Incoming traffic tagged with this
VLAN ID is routed to the corresponding interface. Outgoing traffic from
this interface is tagged with this VLAN ID.
Note: To enable VLANs, use the 'VLAN Mode' parameter.
Interface Name
[InterfaceTable_InterfaceN
ame]
Defines a name for the interface. This name is used in various
configuration tables to associate the network interface with other
configuration entities such as Media Realms. It is also displayed in
management interfaces (Web, CLI, and SNMP) for clarity where it has
no functional use.
The valid value is a string of up to 16 characters.
Primary DNS
[InterfaceTable_PrimaryDN
SServerIPAddress]
(Optional) Defines the primary DNS server's IP address (in dotted-
decimal notation), which is used for translating domain names into IP
addresses for the interface.
By default, no IP address is defined.
Secondary DNS
[InterfaceTable_Secondary
DNSServerIPAddress]
(Optional) Defines the secondary DNS server's IP address (in dotted-
decimal notation), which is used for translating domain names into IP
addresses for the interface.
By default, no IP address is defined.
General Parameters
Web/EMS: VLAN Mode
[VLANMode]
Enables VLANs tagging (IEEE 802.1Q).
 [0] Disable (default)
 [1] Enable
Notes:
 For this parameter to take effect, a device reset is required.
 To operate with multiple network interfaces, VLANs must be
enabled.
 If this parameter is enabled, separate physical networks for Media,
