User's Manual 310 Document #: LTRT-89730
Mediant 3000
Note: For your convenience, the device provides pre-
Experience Profiles. One of these pre-configured profiles is the default Quality of
Experience Profile. Therefore, if you do not configure a Quality of Experience Profile,
this default is used.
The following procedure describes how to configure Quality of Experience Profiles through
the Web interface. You can also configure it through other management platforms:
Quality of Experience Profile table: ini file (QoEProfile)
Quality of Experience Color Rules table: ini file (QOEColorRules)
To configure a QoE Profile:
1. Open the Quality of Experience Profile page (Configuration tab > VoIP menu >
Quality of Experience > Quality of Experience Profile).
2. Click Add; the following dialog box appears:
Figure 17-2: Quality of Experience Profile Table - Add Row Dialog Box
3. Configure a QoE Profile according to the parameters described in the table below.
4. Click Add.
Table 17-1: Quality of Experience Profile Table Parameter Descriptions
Parameter Description
Index
[QOEProfile_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Profile Name
[QOEProfile_Name]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 20 characters.
Sensitivity Level
[QOEProfile_SensitivityLevel]
Defines the pre-configured threshold profile to use.
[0] User Defined = Need to define thresholds per monitored
parameter in the Quality of Experience Color Rules table.
[1] Low = Pre-configured low sensitivity thresholds.
[2] Medium = (Default) Pre-configured medium sensitivity
thresholds.
[3] High = Pre-configured high sensitivity thresholds.
Reporting is done for small fluctuations in parameter values.
