AudioCodes Mediant 3000 User Manual

Version 7.0 317 Mediant 3000
User's Manual 17. Quality of Experience
2. Click Add; the following dialog box appears:
Figure 17-5: Media Enhancement Profile Table - Add Row Dialog Box
3. Configure a Media Enhancement Profile according to the parameters described in the
table below.
4. Click Add.
Table 17-4: Media Enhancement Profile Table Parameter Descriptions
Parameter Description
Index
[MediaEnhancementProfile_Index
]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
[MediaEnhancementProfile_Profil
eName]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 20 characters.
5. In the Media Enhancement Profile table, select the required Media Enhancement
Profile index row, and then click the Media Enhancement Rules link located below
the table; the Media Enhancement Rules page appears.
6. Click Add; the following dialog box appears:
Figure 17-6: Media Enhancement Rules Table - Add Row Dialog Box
7. Configure a Media Enhancement Rule according to the parameters described in the
table below.
8. Click Add, and then reset the device with a save ("burn") to flash memory.
Table 17-5: Media Enhancement Rules Table Parameter Descriptions
Parameter Description
