AudioCodes Mediant 3000 User Manual

User's Manual 320 Document #: LTRT-89730
Mediant 3000
2. Click Add; the following dialog box appears:
Figure 18-1: Media Realm Table - Add Row Dialog Box
3. Configure the Media Realm according to the parameters described in the table below.
4. Click Add.
Table 18-1: Media Realm Table Parameter Descriptions
Parameter Description
Index
[CpMediaRealm_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
[CpMediaRealm_Media
RealmName]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 40 characters.
Notes:
 The parameter is mandatory.
 Each row must be configured with a unique name.
IPv4 Interface Name
[CpMediaRealm_IPv4I
F]
Assigns an IPv4 network interface to the Media Realm. This is the name of
the interface as configured in the 'Interface Name' parameter in the
Interface table.
By default, no value is defined (None).
IPv6 Interface Name
[CpMediaRealm_IPv6I
F]
Assigns an IPv6 network interface to the Media Realm. This is the name of
the interface as configured for the 'Interface Name' parameter in the
Interface table.
By default, no value is defined (None).
Port Range Start
[CpMediaRealm_PortR
angeStart]
Defines the starting port for the range of media interface UDP ports.
By default, no value is defined.
Notes:
 You must either configure all your Media Realms with port ranges or all
without; not some with and some without.
 The available UDP port range is according to the BaseUDPport
parameter. For more information, see ''Configuring RTP Base UDP Port''
on page 215.
 The base UDP port number (BaseUDPPort parameter) must be greater
than the highest UDP port configured for a SIP Interface (see
