AudioCodes Mediant 3000 User Manual

Version 7.0 339 Mediant 3000
User's Manual 18. Control Network
Parameter Description
[SIPInterface_InterfaceN
ame]
configure a name, the device automatically assigns the name
"SIPInterface_<row index>" (e.g., "SIPInterface_1" when added to Index
1).
Network Interface
[SIPInterface_NetworkInt
erface]
Assigns a Control-type IP network interface to the SIP Interface.
By default, no value is defined (None).
For configuring network interfaces, see ''Configuring IP Network
Interfaces'' on page 145.
Note: The parameter is mandatory.
Application Type
[SIPInterface_Application
Type]
Defines the application for which the SIP Interface is used.
 [0] GW = (Default) Gateway application.
 [1] SAS = Stand-Alone Survivability (SAS) application.
 [2] SBC = SBC application.
UDP Port
[SIPInterface_UDPPort]
Defines the device's listening and source port for SIP signaling traffic over
UDP.
The valid range is 1 to 65534. The default is 5060.
Notes:
 The port must be different from ports configured for RTP traffic (i.e.,
ports configured for Media Realms). For example, if the RTP port
range is 6000 to 6999, the SIP port can either be less than 6000 or
greater than 6999.
 The base UDP port number (BaseUDPPort parameter) for RTP traffic
must be greater than the highest UDP port configured for a SIP
Interface. For example, if your highest configured UDP port for a SIP
Interface is 6060, you must configure the BaseUDPPort parameter to
any value greater than 6060. For more information on base UDP port,
see Configuring RTP Base UDP Port on page 215.
 Each SIP Interface must have a unique signaling port (i.e., no two SIP
Interfaces can share the same port - no port overlapping).
TCP Port
[SIPInterface_TCPPort]
Defines the device's listening port for SIP signaling traffic over TCP.
The valid range is 1 to 65534. The default is 5060.
Notes:
 The port must be different from ports configured for RTP traffic (i.e.,
ports configured for Media Realms). For example, if the RTP port
range is 6000 to 6999, the SIP port can either be less than 6000 or
greater than 6999.
 Each SIP Interface must have a unique signaling port (i.e., no two SIP
Interfaces can share the same port - no port overlapping).
TLS Port
[SIPInterface_TLSPort]
Defines the device's listening port for SIP signaling traffic over TLS.
The valid range is 1 to 65534. The default is 5061.
Notes:
 The port must be different from ports configured for RTP traffic (i.e.,
ports configured for Media Realms). For example, if the RTP port
range is 6000 to 6999, the SIP port can either be less than 6000 or
greater than 6999.
 Each SIP Interface must have a unique signaling port (i.e., no two SIP
Interfaces can share the same port - no port overlapping).
