Table 18-6: IP Group Table Parameter Descriptions
Parameter Description
Common Parameters
Index
[IPGroup_Index]
Defines an index for the new table row.
Note: Each row must be configured with a unique index.
SRD
[IPGroup_SRDName]
Assigns an SRD to the IP Group.
If only one SRD is configured in the SRD table, the SRD is assigned by
default. If multiple SRDs are configured in the SRD table, no value is
assigned by default.
For configuring SRDs, see Configuring SRDs on page 326.
Notes:
 The parameter is mandatory.
 For the parameter to take effect, a device reset is required.
Name
[IPGroup_Name]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 40 characters.
Note: Each row must be configured with a unique name.
Type
[IPGroup_Type]
Defines the type of IP Group:
 [0] Server = Applicable when the destination address of the IP Group
(e.g., ITSP, Proxy, IP-PBX, or Application server) is known. The
address is configured by the Proxy Set that is associated with the IP
Group.
 [1] User = Represents a group of users such as IP phones and
softphones where their location is dynamically obtained by the device
when REGISTER requests and responses traverse (or are
terminated) by the device. These users are considered remote (far-
end).
Typically, this IP Group is configured with a Serving IP Group that
represents an IP-PBX, Application or Proxy server that serves this
User-type IP Group. Each SIP request sent by a user of this IP Group
is proxied to the Serving IP Group. For registrations, the device
updates its registration database with the AOR and contacts of the
users.
Digest authentication using SIP 401/407 responses (if needed) is
performed by the Serving IP Group. The device forwards these
responses directly to the SIP users.
To route a call to a registered user, a rule must be configured in the
Tel-to-IP Routing table or SBC IP-to-IP Routing table. The device
searches the dynamic database (by using the Request-URI) for an
entry that matches a registered AOR or Contact. Once an entry is
found, the IP destination is obtained from this entry and a SIP request
is sent to the destination.
The device also supports NAT traversal for the SIP clients located
behind NAT. In this case, the device must be defined with a global IP
address.
 [2] Gateway = (Applicable only to the SBC application.) In scenarios
where the device receives requests to and from a gateway
representing multiple users. This IP Group type is necessary for any
of the following scenarios:

The IP Group cannot be defined as a Server-type since its
address is initially unknown and therefore, a Proxy Set cannot be
