AudioCodes Mediant 3000 User Manual

Version 7.0 611 Mediant 3000
User's Manual 33. Routing SBC
Parameter Description
table).
The default is Any (i.e., any IP Group).
Note: The selectable IP Group for the parameter depends on the
assigned SBC Routing Policy (in the 'Routing Policy' parameter in this
table). For more information, see ''Configuring SBC Routing Policy
Rules'' on page 616.
Action
Destination Type
[IP2IPRouting_DestType]
Determines the destination type to which the outgoing SIP dialog is sent.
 [0] IP Group = (Default) The SIP dialog is sent to the IP Group as
defined in the 'Destination IP Group'
(IP2IPRouting_DestIPGroupName) parameter. For more information
on the actual address, see the 'Destination IP Group' parameter.
 [1] Dest Address = The SIP dialog is sent to the address configured
in the following parameters: 'Destination Address', 'Destination Port'
and 'Destination Transport Type'.
 [2] Request URI = The SIP dialog is sent to the address indicated in
the incoming Request-URI. If the fields 'Destination Port' and
'Destination Transport Type' are configured, the incoming Request-
URI parameters are overridden and these fields take precedence.
 [3] ENUM = An ENUM query is sent to include the destination
address. If the fields 'Destination Port' and 'Destination Transport
Type' are configured, the incoming Request-URI parameters are
overridden and these fields take precedence.
 [4] Hunt Group = Used for call center survivability. For more
information, see ''Call Survivability for Call Centers'' on page 649.
 [5] Dial Plan = The IP destination is determined by a Dial Plan index
of the loaded Dial Plan file. The syntax of the Dial Plan index in the
Dial Plan file is as follows: <destination / called prefix number>,0,<IP
destination>
Note that the second parameter "0" is ignored. An example of a
configured Dial Plan (# 6) in the Dial Plan file is shown below:
[ PLAN6 ]
200,0,10.33.8.52 ; called prefix 200 is
routed to destination 10.33.8.52
201,0,10.33.8.52
300,0,itsp.com ; called prefix 300 is
routed to destination itsp.com
Once the Dial Plan is defined, you need to assign it (0 to 7) to the
routing rule as the destination in the 'Destination Address' parameter,
where "0" denotes [PLAN1], "1" denotes [PLAN2], and so on.
 [7] LDAP = LDAP-based routing. Make sure that the Routing Policy
assigned to the routing rule is configured with the LDAP Server Group
for defining the LDAP server(s) to query.
 [8] Gateway = The device routes the SBC call to the Tel side
(Gateway call) using an IP-to-Tel routing rule in the Inbound IP
Routing table (see Configuring IP to Trunk Group Routing Rules on
page 505
). The IP-to-Tel routing rule must be configured with the
same call matching characteristics as this SBC IP-to-IP routing rule.
This option is also used for alternative routing of an IP-to-IP route to
the PSTN. In such a case, the IP-to-Tel routing rule must also be
configured with the same call matching characteristics as this SBC
