User's Manual 612 Document #: LTRT-89730
Mediant 3000
Parameter Description
IP-to-IP routing rule.
 [9] Routing Server = Device sends a request to a third-party routing
server for an appropriate destination (next hop) for the matching call.
 [10] All Users = Device checks whether the Request-URI (i.e.,
destination user) in the incoming INVITE is registered in its' users’
database, and if yes, it sends the INVITE to the address of the
corresponding contact specified in the database. If the Request-URI
is not registered, the call is rejected.
Destination IP Group
[IP2IPRouting_DestIPGro
upName]
Defines the IP Group to where you want to route the call. The actual
destination of the SIP dialog message depends on the IP Group type (as
defined in the 'Type' parameter):
 Server-type IP Group: The SIP dialog is sent to the IP address
configured for the Proxy Set that is associated with the IP Group.
 User-type IP Group: The device checks if the SIP dialog is from a
registered user, by searching for a match between the Request-URI
of the received SIP dialog and an AOR registration record in the
device's database. If found, the device sends the SIP dialog to the IP
address specified in the database for the registered contact.
By default, no value is defined (None).
Notes:
 The parameter is only relevant if the parameter 'Destination Type' is
set to IP Group.
 The selectable IP Group for the parameter depends on the assigned
SBC Routing Policy (in the 'Routing Policy' parameter in this table).
For more information, see ''Configuring SBC Routing Policy Rules''
on
page 616.
Destination SIP Interface
[IP2IPRouting_DestSIPInt
erfaceName]
Defines the destination SIP Interface to where the call is sent.
By default, no value is defined (None).
For configuring SIP Interfaces, see ''Configuring SIP Interfaces'' on page
337.
Notes:

The parameter is applicable only if the 'Destination Type' parameter is
configured to any value other than IP Group. If the 'Destination Type'
parameter is configured to IP Group, the following SIP Interface is
used:

Server-type IP Groups: SIP Interface that is assigned to the
Proxy Set associated with the IP Group.

User-type IP Groups: SIP Interface is determined during user
registration with the device.
 For multi-tenancy, if the assigned SBC Routing Policy is not shared
(i.e., the Routing Policy is associated with an Isolated SRD), the SIP
Interface must be one that is associated with the Routing Policy or
with a shared Routing Policy (i.e., the Routing Policy is associated
with one or more Shared SRDs). If the Routing Policy is shared, the
SIP Interface can be one that is associated with any SRD or Routing
Policy (but it's recommended that it belong to the same SRD/Routing
Policy or to shared SRD/Routing Policy to avoid "bleeding").
Destination Address
[IP2IPRouting_DestAddre
ss]
Defines the destination address to where the call is sent. The address
can be an IP address or a domain name (e.g., domain.com).
If ENUM-based routing is used (i.e., the 'Destination Type' parameter is
set to ENUM) the parameter defines the IP address or domain name
