User's Manual 628 Document #: LTRT-89730
Mediant 3000
2. Click Add; the following dialog box appears:
Figure 34-3: IP to IP Outbound Manipulation Table- Add Row Dialog Box
3. Configure an IP-to-IP outbound manipulation rule according to the parameters
described in the table below.
4. Click Add.
Table 34-2: IP to IP Outbound Manipulation Table Parameter Description
Parameter Description
Index
[IPOutboundManipulation
_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Routing Policy
[IPOutboundManipulation
_RoutingPolicyName]
Assigns an SBC Routing Policy to the rule. The SBC Routing Policy
associates the rule with an SRD(s). The SBC Routing Policy also defines
default LCR settings as well as the LDAP servers if the routing rule is
based on LDAP routing (and Call Setup Rules).
If only one SBC Routing Policy is configured in the SBC Routing Policy
table, the SBC Routing Policy is automatically assigned. If multiple SBC
Routing Policies are configured, no value is assigned.
For configuring SBC Routing Policies, see ''Configuring SBC Routing
Policy Rules'' on page 616.
Note: The parameter is mandatory.
Manipulation Name
[IPOutboundManipulation
_ManipulationName]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 20 characters. By default, no value is
defined.
Rule (Matching Characteristics)
