User's Manual 706 Document #: LTRT-89730
Mediant 3000
12. When you have completed loading all the desired files, click Next until the last
wizard page appears (the FINISH button is highlighted in the left pane):
Figure 44-9: Software Upgrade Wizard - Files Loaded
13. Click Reset to burn the files to the device's flash memory; the "Burn and reset in
progress" message is displayed and the device 'burns' the newly loaded files to flash
memory and then resets.
Note: Device reset may take a few minutes (even up to 30 minutes), depending on
.cmp file version.
When the device finishes the installation process and resets, the following wizard
page is displayed, showing the installed software version and other files (ini file and
Auxiliary files) that you may also have installed:
Figure 44-10: Software Upgrade Process Completed Successfully (Example)
14. Click End Process to close the wizard; the Web Login dialog box appears.
15. Enter your login username and password, and then click Login; a message box
appears informing you of the new .cmp file version.
16. Click OK; the Web interface becomes active, reflecting the upgraded device.
