User's Manual 812 Document #: LTRT-89730
Mediant 3000
2. Click Add; the following dialog box appears:
Figure 56-1: Test Call Table - Add Row Dialog Box
3. Configure a test call according to the parameters described in the table below.
4. Click Add, and then save ("burn") your settings to flash memory.
Table 56-1: Test Call Table Parameter Descriptions
Parameter Description
Common Tab
Endpoint URI
[Test_Call_Endpoint
URI]
Defines the endpoint's URI. This can be defined as a user or user@host. The
device identifies this endpoint only by the URI's user part. The URI's host part
is used in the SIP From header in REGISTER requests.
The valid value is a string of up to 150 characters. By default, the parameter
is not configured.
Note: The parameter is mandatory.
Called URI
[Test_Call_CalledURI
]
Defines the destination (called) URI (user@host).
The valid value is a string of up to 150 characters. By default, the parameter
is not configured.
