AudioCodes Mediant 3000 User Manual

Version 7.0 813 Mediant 3000
User's Manual 56. Testing SIP Signaling Calls
Parameter Description
Route By
[Test_Call_RouteBy]
Defines the type of routing method. This applies to incoming and outgoing
calls.
 [0] GW Tel2IP = (Default) Calls are matched by (or routed to) an SRD and
Application type (defined in the SRD and Application Type parameters
below).
 [1] IP Group = Calls are matched by (or routed to) an IP Group. To specify
the IP Group, see the 'IP Group' parameter in the table.
 [2] Dest Address = Calls are matched by (or routed to) an SRD and
application type. To specify the address, see the 'Destination Address'
parameter in the table.
Notes:
 If configured to GW Tel2IP or Dest Address, you must assign a SIP
Interface (see the 'SIP Interface' parameter in the table).
 For REGISTER messages:

The GW Tel2IP option cannot be used as the routing method.
 If configured to IP Group, only Server-type IP Groups can be used.
IP Group
[Test_Call_IPGroupN
ame]
Assigns an IP Group to the rule, wh
ich is the IP Group that the test call is sent
to or received from.
By default, no value is defined (None).
Notes:
 The parameter is applicable only if the 'Route By' parameter is configured
to IP Group [1].
 The IP Group is used for incoming and outgoing calls.
Destination Address
[Test_Call_DestAddr
ess]
Defines the destination host. This can be defined as an IP address[:port] or
DNS name[:port].
Note: The parameter is applicable only if the 'Route By' parameter is
configured to Dest Address [2].
SIP Interface
[Test_Call_SIPInterfa
ceName]
Assigns a SIP Interface to the rule, which is the SIP Interface to which the test
call is sent and received from.
By default, no value is defined (None).
Note: The parameter is applicable only if the 'Route By' parameter is
configured to GW Tel2IP or Dest Address.
Application Type
[Test_Call_Applicatio
nType]
Defines the application type for the endpoint. This associates the IP Group
and SRD to a specific SIP interface. For example, assume two SIP Interfaces
are configured in the SIP Interface table where one is set to "GW" and one to
"SBC" for the 'Application Type'. If the parameter is set to "SBC", the device
uses the SIP Interface set to "SBC".
 [0] GW (default) = Gateway application
 [2] SBC = SBC application
Destination Transport
Type
[Test_Call_DestTrans
portType]
Defines the transport type for outgoing calls.
 [-1] = Not configured (default)
 [0] UDP
 [1] TCP
 [2] TLS
Note:
The parameter is applicable only if the 'Route By' parameter is set to [2]
(Dest Address).
