User’s Manual—SNAP™ 500 Gen 1 and Gen 2 103
Classification: Avery Dennison - Public
Panel
Dimensions
18.5" (470mm) high x 25" (635mm) wide
Including stacker x 20.0" (508.0mm) deep
Weight
50 lbs. (22.7 Kg.)
65 lbs. (29.5 Kg.) Shipping Weight with carton, printer, stacker, accessories
Electrical
100-240 VAC 50-60Hz – 3.0 / 1.5 Amp 1 Ph Auto Strapping
Temperature
40F (4C) to 95F (35C)
Humidity
5% to 90% non-condensing
Sound Level
Pressure
(SPL)
less than 80 dB Maximum
Other
Features
- - Downloading of information while machine is operating
- - Sequenced Fields
- - Time/Date Stamping (Both month/day/year and day/month/year format)
- - Life Counts – Through PCMate or Remote Control/Display Module
- - Operator adjustable: Contrast – Adjustable on printhead
- Cut position, print position and baud rate – Adjustable through PCMate
virtual display or optional remote display
- - Error Detection of: Stock out, ink out, print head open, feed open, full stacker,
stacker jam, and print head over-temperature – with voice commands.
- - Display: Labels left to be cut and stacked in a batch, batch ID, total life inches,
total life cuts
- - Self Diagnostics – Through PCMate
- - Missed sense mark detection and correction
Ink Ribbon
AVERY DENNISON standard thermal colors and widths
AVERY DENNISON white plastic core: Maximum Ink I.D. 3.5”
Ink widths:
With Metric Adapter - 25mm, 30mm, 35mm 40mm, 45mm, 50mm or 60mm
metric widths only.
With Inch Adapter - 1”, 1 ¼”, 1 ½” 1 ¾”, 2”, 2 ¼” or 2 ½” inch widths only.
Options
- Back reflective sensor — Reads black sense mark printed on back of white
preprinted tape, centered in web.
- Contrast sensor — Reads sense mark printed on front of preprinted tape. Sense
mark or tape may be colored.
Serial Port
Default
Setup
Default serial port configuration is 115,200 baud, no parity, 8 data bits, 1 stop bit.
