11.3 Printer Specifications
Print method:
Narrow web thermal transfer two sided printer
Speeds - 3 IPS (76.2mm/second), 4.5 IPS (114.3mm/second), 5 IPS (127mm /
second), 6 IPS (152.4mm/second), 7 IPS (177.8mm/second)
Label Size
Gen 1 standard feed:
Min: 1/2" (12.7mm) web x 1.013" (25.73mm) feed at 3 IPS (standard stacker)
Gen 1 short feed option, Gen 2 standard feed:
Min: 1/2" (12.7mm) web x .725" (18.42mm) feed at 3 IPS (standard stacker)
Min: 1/2" (12.7mm) web x .775" (19.69mm) feed at 4.5 IPS (standard stacker)
Min: 1/2" (12.7mm) web x .840" (21.34mm) feed at 5 IPS (standard stacker)
Min: 1/2" (12.7mm) web x 1.013" (25.73mm) feed at 6 IPS (standard stacker)
Min: 1/2" (12.7mm) web x 1.057" (26.85mm) feed at 7 IPS (standard stacker)
Both Gen printers:
Max: 2 1/8" (54mm) web x 5" (127mm) feed (standard stacker)
5:1 web feed to width ratio
2 1/8" (54mm) web x 14" (355.6mm) feed - No stacker – optional rewind unit or
cut without stacking.
Stacker capacity: Standard coated tape approximately 2,000 label for full stacker.
Print Area
Min: 1 dot
Max: Up to 2" (50.8 mm) web x up to 13.875" (352.4 mm) feed -
Resolution
305 dots per inch (12 dots per mm)
609 dots per inch (24 dots per mm)
Fonts
True Type – English alphabet, Cyrillic, and Asian characters.
4pt up to 96pt (300DPI), Supply dependent on 4, 5 and 6 point characters
All rotations 0°, 90°, 180°, 270°
Logos
No restriction on number or size per tag (up to maximum image area)
All rotations 0°, 90°, 180°, 270°
Care
Symbols
Full Ginetex Care Symbol set and full NAFTA / ASTM Care Symbol Set
Fully Scalable
All rotations 0°, 90°, 180°, 270°
Justification
Left, Right, and Center field selectable
Stock
Support for blank or pre-printed fabrics, coated or uncoated polyester, woven labels,
dip-coated nylons and heat seal tapes.
Supply Roll: 3” ID (76 mm) cardboard core, Maximum roll size 11.5” O.D. (29 cm)
Interface
Null modem serial cable DB9 F connector
May require USB/serial adapter
May require external Ethernet adapter
Control
Push-button start/stop with 4 LED lights – Ready, Data, Supply, Error voice button
