The D800-Dante sends the following outputs into a Dante network from Personal Mixers connected
to its eight front-panel A-Net ports:
D800 Port Mixes Out Dante Channels
1 1-2
2 3-4
3 5-6
4 7-8
5 9-10
6 11-12
7 13-14
8 15-16
The front-panel I/II switches on the D800-Dante must be in the “II” position to
use the Network Mix Back feature.
