CHAPTER 4 – Installation
Chap. 4
- 17/20 -
4.6 Installation site requirements
The site where the machine is to be positioned must meet certain requirements. The buyer is
responsible for preparing the machine’s site of installation.
4.6.1 Floor specifications
The site where the machine is to be positioned must meet certain requirements. The buyer is
responsible for preparing the machine’s site of installation.
For machine installation, an industrial type floor made of plain concrete (or a similar material), at least 20
cm thick, will suffice.
The surface must be flat (maximum admissible inclination of 2:1000).
If the concrete is reinforced with a steel grid, the grid must be deep enough under the surface of the
floor, seeing as the machine is installed using anchoring bolts that reach a depth of 15 cm.
Ditches for the removal of dust and chips must be at a distance of at least 10 cm from the machine’s
resting feet.
TYPE DESCRIPTION
Type of floor Industrial cement
Floor thickness At least 20 cm
Surface planarity 2:1000
Distance from the surface of reinforcement
grid
> 15 cm
Distance of ditches from resting feet > 10 cm
4.6.2 Ambient data
Proper machine efficiency depends on the following ambient conditions.
CRITERIA SPECIFICATION
Temperature Between +5°C and 47°C
Relative humidity Between 10% and 90%
