CHAPTER 3 – Machine description and technical data
3.8 Technical data
INFORMATION!
The paragraphs that follow contain the main technical data for the machine, or in any event
the minimum and maximum obtainable performance output; this data may differ based on
specific customer requirements.
3.8.1 Machine technical data
TYPE DESCRIPTION
Number of interpolated axes 6
Axis strokes
Longitudinal X-axis (standard) 2200 mm
Longitudinal X-axis (optional) 3400/4400 mm
Transverse Y-axis 1800 mm
Contouring capacity along Y direction 1200 mm
Z vertical axis 1250 mm
B rotating axis unlimited
C rotating axis 400°
Speed
X-axes 100 m/min
Y and Z axes 60 m/min
Spindles
Rated power (S1) 10 Hp / 7,5 kW
Rotation speed 0 - 24.000 1/min
Direction of rotation Clockwise and counterclockwise
Machining tables
Number of tables 2
Dimensions including stroke
X-axis = 2200 mm 4500x5100x2200 mm
X-axis = 3400 mm (optional) 6000x5100x2200 mm
