TWIN – Use and maintenance instruction manual
Chap. 2
- 46/52 -
2.16.8.2 SINGLE PITCH loading/unloading (work cycle) – (Risk ID: 12.02)
IDENTIFICATION RISK ASSESSMENT
Stage: Use
Person: Operator
Area: Z02 Material loading/unloading area
Initial risk: LOW
RESIDUAL RISK: LOW
PLr (EN 13849): -
SIL (EN IEC 62061): -
ACCIDENT SCENARIO
Consequence:
1.3 Crushing
1.8 Collision
Situation:
Loading and unloading piece/s to/from the table.
Event:
Risk of crushing and collision resulting from the piece/s falling from the table.
Body part:
Hands, fingers, feet, lower limbs.
RESIDUAL RISK
Risk of crushing and collision resulting from the piece falling from the clamps.
LIMITATION MEASURES
Mechanical:
-
Electrical:
-
Informative:
The piece must be loaded by correctly placing it on the specific support device.
After checking the stability of the piece, lock it by stepping on the specific pedal
located near the table.
The piece must be unloaded by stepping on the specific pedal located near the
table, to open the support device. Firmly grasp the piece, then step on the pedal to
open the support device, then remove the piece. Lay the piece on the floor or in
specific containers.
Symbols:
-
