CHAPTER 3 – Machine description and technical data
3.8.7 Spaces for use and maintenance
INFORMATION!
Space requirements for use and maintenance must be verified on the machine’s main installation
layout drawing, which must always be consulted.
The presence of structural elements such as, for example, walls, columns, etc., or work equipment
in the area destined to machine use and maintenance may render proper installation impossible.
The user may therefore be required to carry out structural work to adapt the site to machine
installation before the machine may be installed and started up.
Space requirements for use and maintenance are shown in the main layout drawing (see ANNEX
B TECHNICAL DIAGRAMS AND GENERAL INFORMATION).
3.8.8 Tool technical characteristics
Use only tools having the diameters and weights shown in the table below.
COUPLING SIZE MAX TOOL SHAFT
DIAMETER (MM)
ROTATION SPEED
(RPM)
MAX TOOL
DIAMETER (MM)
MAX TOOL
WEIGHT (KG)
ER40
25
6000 / 9000 150 10
9000 / 12000 130 7
12000 / 15000 110 5
15000 / 18000 80 5
ER32
20
6000 / 9000 140 4
9000 / 12000 130 4
12000 / 15000 110 2.5
15000 / 18000 80 2.5
DANGER!
Risk of flying tool parts
Improper tool balancing may cause:
• The tool to break, or
• The tool to come free from the spindle.
• Balance tools and tool holders in G1. Rebalance every time they are sharpened.
