CHAPTER 5 – Controls and use
Chap. 5
- 15/48 -
STEP ACTION DESCRIPTION
5
Check
pneumatic air
supply
pressure.
Check the pneumatic supply air pressure.
Initial regulation of pressure gauges:
• Check that the pressure gauge for the balancing cylinders (2) shows a
working pressure of 6 bar.
If the pressure shown is not the working pressure, use the pressure
regulator for the balancing cylinders (1) to increase or decrease the
pressure as required.
• Check that the pressure gauge for the doors/piece clamps (5) shows a
working pressure of 6 bar.
If the pressure shown is not the working pressure, use the
pressure regulator for the doors/piece clamps (1) to increase or
decrease the pressure as required.
• Check that the spindle cooling pressure gauge shows a working
pressure of 6 bar.
If the pressure shown is not the working pressure, use the
pressure regulator for the spindle cooler (1) to increase or decrease the
pressure as required.
2
3
