TWIN – Use and maintenance instruction manual
Chap. 5
- 30/48 -
STEP DESCRIPTION
3
Working cycle execution (CNC program).
− Manual loading of the piece.
− Low-pressure locking of the piece through the clamps, performed by the operator
by means of the foot control.
− The operator issues a CYCLE START command.
− The machine automatically closes the door. Once the door is closed, the clamps
lock the piece at high pressure.
− Programmed operation sequence.
− Processing stop and retraction of piece supports.
− Door opening, to allow manual unloading of the processed piece. Depending on
the configuration selected in the control software, the pressers may open
automatically, when the support devices are positioned, or the opening must be
carried out by the operator via the pedal command.
− Manual loading of the next workpiece and repetition of the working cycle.
